TFDG-PK - Catalytic gas detector IP55

Catalytic gas detector with proportional 4-20mA output - Zero tracking and self-test – Plug-in calibration tool – Optional 3-relay board (to be mounted inside the casing) – Operating voltage 12V...24V DC – Max. consumption 90mA @ 12V – Operating temperature -10°C…+60°C – IP55 – Die-cast aluminum casing – Dimensions (L x H x D) 100 x 180 x 65mm - EMC EN 50270:2011, EN 61000

Catalytic gas detector IP55

Dimensions (L x H x P) 100 x 180 x 65mm
