TFDG-EXN - Gas detector with electrochemical cell EXN

Gas detector with electrochemical cell and proportional 4-20mA output for zone 1 category 2 - Operating pressure 80KPa…110KPa – Max. air velocity <6m/s – Zero tracking and self-test – Plug-in calibration tool – Optional 3-relay board (to be mounted inside the casing) – Operating voltage 12V...24V DC – Max. consumption 70mA @ 12V – Die-cast aluminum casing – Dimensions (L x H x D) 106 x 170 x 65mm - ATEX EXD II2G, SIL1, EMC EN 50270:2011, EN 61000

Dimensions (L x H x D) 106 x 170 x 65mm
