TFDF-EX IR2 - IR2 flame detector EXD

Dual infrared (IR2) flame detector Operating range 0.75μm…2.7μm – Outputs: proportional 4-20mA, alarm relay and failure relay – High immunity to light interference – High smoke, vapor and dust tolerance – Programmable response time and sensitivity – Self test – Operating voltage 14V...30V DC – Stand-by consumption 8mA – Operating temperature -10°C…+55°C – EXD – IP66 – Aluminum casing – Dimensions (L x H x D) 146 x 150 x 137mm SIL2, ATEX, EN 54-10 – Certification number 0832-CPR-F0577

Item no.

Description

TF14TFDFIR2EX Dual infrared (IR2) flame detector - Operating range 0.75μm…2.7μm – Outputs: proportional 4-20mA, alarm relay and failure relay – High immunity to light interference – High smoke, vapor and dust tolerance – Programmable response time and sensitivity – Self test – Operating voltage 14V...30V DC – Stand-by consumption 8mA – Operating temperature -10°C…+55°C – EXD – IP66 – Aluminum casing – Dimensions (L x H x D) 146 x 150 x 137mm - SIL2, ATEX, EN 54-10
