Catalytic detector. Operating pressure 80KPa...110KPa, maximum air speed <6m/s.
Zero tracker and self-diagnosis. Plug-in calibration tool. 4-20mA proportional signal output. Optional 3 relay board that can be housed in the casing. 12V...24V DC supply voltage.
Maximum consumption 130mA @ 12V. Operating temperature -20°C...+50°C.
Protection rating IP55. Die-cast aluminum casing. Dimensions (L x H x D) 106 x 170 x 65mm.
Approved EMC EN 50270:2011, EN 61000. Certification: ATEX Exn II3G e SIL1.
